In this video I showed how do to put more than one DVR Stand Alone on the same network. I explained that it is necessary to assign two different IP’s to the DVRs and also different doors for them. Below is a good example of how to organize the port forwarding on the router:
WEB port – 8080
WEB port – 8081
Note that I just changed one last IP number and the doors, because that way, the redirect on the router is more organized.
Likewise, if you have more than 2 DVR’s on the same network, follow this same schema that everything will be all right.
If the your network has a different interface, for example, 10.0.0.1 the release should be made exactly as I showed above, because despite the IP’s classes are different, the publication scheme of doors is the same.
HOW To CONFIGURE TWO Or MORE DVRs On The SAME NETWORK
Personal speaking, welcome to another CCTV video club, I am the Everton and I prepared this special video for you to speak up, installing and configuring more than one DVR on the same network.
We will begin by following, in general we typically find, or provider modem modem router, and router, modem and router. And then we put our DVR, okay? I already showed that here in another video, how do you do a setting in the default method, I’ll put the link here, in case you haven’t seen, you can watch here. In this case, this explanation that I’ll give about the setting, she goes for you put two, three, four to five DVRs, ten, no matter, on the same network, she will adapt to your need. Well, in a default configuration, we get there, for example, the DVR Intelbras, he has two ports, we need to open the router, free and direct on the router.
It comes with the door 37777 and comes with the WEB port is port 80, we always recommend that you replace the door by another door. We take so that port 3777, points her to the router to the IP that you have already set the DVR, released and a hug, going to work, okay? And when you have two, and these two DVRs, they are the same, for example, two Intelbras, two Tecvoz, two lux, two igualzinhos.
When one of each brand, some people are kinda lucky and end up getting and such, because for being of different brand, they come each with your group of ports there, and just not in the conflict, will you release, each has your IP, and going to work. When they are the same brand and they have the same Doors, it is interesting that you make the change, and I for example, recommend, if it’s a Tecvoz that comes with the door 6036, first you do 6036 and second you put 6037.
Does not have a rule, you will test this port on the network, see if it exists, usually does not exist, four digits, they are, has a very big variation, so that means there is no door. It’s very difficult you have conflict with door, okay? Can be, but it’s very difficult. So I’ve always, for example if Intelbras 37777, I ask for the person putting 37778, is more to organize, if you put 5 DVRs, you’ll get there, a lot of doors all messy? Don’t you always puts a little there to be easy to set. And the same way you do it also in WEB access.
And there you have so suppose, Let’s imagine that we have two DVRs, a people defined the IP 192.168.1.100 and the other we defined 1,101. At first you will release, if Intelbras, 37777 and second, 37778 and also WEB. So in this case we have ready access to two DVRs on the same network, so there are people who question how “Oh, I need to do two addresses? One for each DVR? “, not necessarily, okay? Can do? Can, going to work, gives no problem, but it is not necessary.
Generally so, Oh you put in a company, where they will be two there, one will shoot a group of indoor cameras, and the other a group of external cameras, and there are different people who will access the internal and the external. Hence you do two addresses, discloses the address for that, an address to a group, the other to another that they will be able to access, okay? So for the purposes of rule or the Organization, create a rule for access, you can create without any problem, but it is not necessary, because, there are many people who will find it silly, but many people also don’t know.
The DDNS, the domain that we create there, he serves to always bring the current internet IP where you allocate it, so you got installed the DVR here, put the DDNS here, he will always return to you are accessing the current IP of that network. As IP is a service, is a unique number for everyone who is on the network, so there’s no need to make two addresses by responding to the same IP, or three, or four. You can do as I told you, but it’s not necessary, one is about to serve, you will differentiate the access through the doors, if you are using a CMS from the manufacturer of the program to install on your PC, you will define who’s who through the command, and if you are accessing via WEB browser, you will define who’s who through the WEB port , that’s why there are doors
Another cool tip is just about the CMS, for example, currently they are well, enhanced if you put, I believe in the pattern, they access, now I won’t remember, if they’re 32 or 64 cameras. So let’s imagine they are 32 cameras, then you have 4 stores, and each of these stores have 8 cameras, who is accessing, if the person has a place, a machine with the big screen and such, and you want to put a CMS, which capture the 32 images, four locations, eight each, he does also and if these four DVRs are in the same company , on the same network, at the same site, also from the right. And that is why it is important that you organize well the change of the ports you want.
And that’s it guys, there’s not much secret, is more an exchange of ideas regarding this subject, because the theory is pretty simple, I think I didn’t spend five minutes to talk about that, but in practice, people often confused, why not create that involvement with the project, sometimes you get on the net and you don’t know where to start and such and this video is a good start for this, understand that each equipment needs of your IP number, you need to define separate ports for the same equipment, and there is only you access the router, release, mapping this access there, redirect ports inside the router.
We have here in the channel, a video that talks about port forwarding in the router and if you are interested in understanding a little better, or learn to flush doors, network map, you just access, I’ll leave the link here also this video, you access and follow up with the people there. Cool, any questions comments there in the video, send an email to us, enjoy our Facebook page, visit our website. Thanks and until the next video.
